Description
Thanks to its enormous compaction force combined with a quick forward and return travel, the DPU 6555 offers an extremely high level of productivity. It is a very versatile machine for all construction sites where extreme demands are placed on the performance efficiency. In addition, it offers excellent characteristics in terms of service life and operating comfort. Optimal application areas are the compaction of frost coverings and bearing layers in street, path and parking lot construction as well as backfilling buildings. Thanks to a frequency of 69 Hz, the DPU 6555 is universally applicable and even reliably compacts heavy interlocking paving stones. The model version DPU 6555Hec is equipped with Compatec, the compaction control by Wacker Neuson. This is also available as a retrofit kit for all DPU 6555He models starting with the year 2011.
Specifications
Manufacturer
Wacker Neuson
Model
DPU6555Hech US
Year
2026
Category
Compactors
Subcategory
Reversible Vibratory Plates
Advance travel max (dependent on soil and environmental influences) ft/min
91.8
Advance travel max (dependent on soil and environmental influences) m/min
28
Base plate size W x L in
21.7 x 35
Base plate thickness in
0.5
Base plate thickness mm
12
Centrifugal force kN
65
Centrifugal force lbf
14,612
Frequency Hz
69
Fuel consumption US gal/h
0.5 gal/h
Hand-arm vibrations ft/s²
4.3
Hand-arm vibrations m/s²
1.3
Surface capacity max (dependent on soil and environmental influences) ft²/h
12,917
Surface capacity max (dependent on soil and environmental influences) m²/h
1,200
Base plate size W x L mm
550 x 900
Height (ground clearance) in
33.6
Height (ground clearance) mm
861
Operating weight kg
497
Operating weight lb
1,096
Operating width (with extension plates) in
28
Operating width (with extension plates) mm
710
Shipping weight kg
502
Shipping weight lb
1,108
Transport height in
59.9
Transport height mm
1,521
Transport length in
41.7
Transport length mm
1,060
Transport width in
30.7
Transport width mm
780
