Description
The minimum swing radius ET65 track excavator is powered by an economical 58.6-hp Perkins Tier 4 Final engine. It is one of the strongest machines in its weight class and performs more like a machine in the next size weight class. This 6.5-ton excavator offers one of the smoothest and most powerful hydraulic systems on the market. An in-cab electronic control pattern changeover is standard.
Specifications
Manufacturer
Wacker Neuson
Model
ET65
Year
2026
Category
Excavators
Subcategory
Tracked Conventional Tail Excavators
Arm displacement to centre of bucket, left side
19.4 in
Arm displacement to centre of bucket, right side
30.2 in
Biting force max
6,924 lbf
Boom slewing radius - Left
74.9 in
Boom slewing radius - Middle
96.6 in
Boom slewing radius - Right
93.4 in
Breakout force max
11,398 lbf
Cabin - specified sound pressure level LpA according to ISO 6394
77 dB(A) LpA
Chain width
15.7 in
Digging depth max
162.4 in
Digging depth max - Long Dipperstick
162.4 in
Digging depth max - Standard Dipperstick
150.6 in
Digging radius max
256.1 in
Digging radius max - Long Dipperstick
6,504 mm
Digging radius max - Standard Dipperstick
244.9 in
Dump height max - Long Dipperstick
161.2 in
Dump height max - Standard Dipperstick
154 in
Dumping height
154 x 161.2 in
Duty pump
Variable displacement pump and gear pump
Height
2,478 mm
Height - Dozer blade
16.7 in
Insertion depth - Long Dipperstick
104.6 in
Insertion depth - Standard Dipperstick
93.8 in
Insertion height - Long Dipperstick
234.4 in
Insertion height - Standard Dipperstick
227.3 in
Lift height -Above ground
15.9 in
Operating pressure for working and driving hydraulics
3,481 psi
Operating pressure swing gear
3,118 psi
Range - Long Dipperstick
251.5 in
Range - Standard Dipperstick
240 in
Rear swivel radius - with Counterweight
58.3 in
Rear swivel radius - w/o Counterweight
53.7 in
Scraping depth - Below ground
16.8 in
Sound level (LwA) according to 2000/14/EC
98 dB(A)
Stroke - Above ground
15.9 in
Stroke - Below ground
16.8 in
Superstructure slewing speed
9 rev/min
Transport length - Long Dipperstick
241.3 in
Transport length - Standard Dipperstick
241.6 in
Travel speed max
3.2 mph
Turning angle - Boom system to the left
67 °
Turning angle - Boom system to the right
63 °
Width
1,950 mm
Width - Dozer blade
76.8 in
Width - Revolving superstructure
74.4 in
Ground clearance
11.2 in
Height
97.6 in
Height - Dozer blade
423 mm
L x W x H
241.6 x 76.8 x 97.6 in
Length - Track
2,516 mm
Operating weight
13,400 - 15,331 lb
Shipping weight min
5,806 kg
Transport length - Long Dipperstick
6,128 mm
Transport length - Standard Dipperstick
6,137 mm
Width
76.8 in
Width - Cab
39.4 in
Width - Chasiss
76.8 in
Width - Dozer blade
1,950 mm
Width - Revolving superstructure
1,891 mm
