Description
The EZ26 compact excavator combines the advantages of a minimal tail swing excavator with a well-designed cabin An innovative front window mechanism for easy ventilation, joystick support, wide cabin entry as well as the arrangement of operating and display elements of the EZ26 are ergonomically and perfectly adapted to the needs of your workplace.
Specifications
Manufacturer
Wacker Neuson
Model
EZ26
Year
2026
Category
Excavators
Subcategory
Tracked Zero Tail Excavators
Biting force max
15.3 kN
Breakout force max
22.5 kN
Superstructure slewing speed
10.2 1/min
Travel speed max
3.8 km/h
Sound level (LwA) acc to 2000/14/EC
93 dB(A)
Cabin - specified sound pressure level LpA acc to ISO 6394
79 dB(A)
Digging depth max
2,744 mm
Dumping height
2,840 - 3,087 mm
Digging radius max
4,806 mm
L x W x H
4,255 x 1,570 x 2,408 mm
Chain width
300 mm
Ground clearance
277 mm
Dozer Blade Width
1,570 mm
Dozer Blade Height
290 mm
Stroke max above ground
380 mm
Stroke max below ground
419 mm
Height
2,414 mm
Height with VDS
2,524 mm
Width of the cabin
970 mm
Width of the revolving superstructure
1,340 mm
Width of the undercarriage
1,570 mm
Transport length (short DS)
4,266 mm
Transport length (short DS) with VDS
4,199 mm
Transport length (long DS)
4,272 mm
Transport length (long DS) with VDS
4,199 mm
Digging depth max (short DS)
2,544 mm
Digging depth max (short DS) with VDS
2,418 mm
Digging depth max (long DS)
2,744 mm
Digging depth max (long DS) with VDS
2,617 mm
Insertion depth max vertical (short DS)
1,962 mm
Insertion depth max vertical (short DS) with VDS
1,845 mm
Insertion depth max vertical (long DS)
2,152 mm
Insertion depth max vertical (long DS) with VDS
2,035 mm
Insertion height max (short DS)
4,169 mm
Insertion height max (short DS) with VDS
4,300 mm
Insertion height max (long DS)
4,299 mm
Insertion height max (long DS) with VDS
4,430 mm
Dump height max (short DS)
2,840 mm
Dump height max (short DS) with VDS
2,960 mm
Dump height max (long DS)
2,970 mm
Dump height max (long DS) with VDS
3,087 mm
Digging radius max (short DS)
4,613 mm
Digging radius max (short DS) with VDS
4,614 mm
Digging radius max (long DS)
4,805 mm
Digging radius max (long DS) with VDS
4,806 mm
Range max ground coverage (short DS)
4,481 mm
Range max ground coverage (short DS) with VDS
4,443 mm
Range max ground coverage (long DS)
4,681 mm
Range max ground coverage (long DS) with VDS
4,644 mm
Rear swivel radius
759 mm
Arm displacement max boom offset to center of bucket, right side with VDS
765 mm
Arm displacement max boom offset to center of bucket, left side
533 mm
Arm displacement max boom offset to center of bucket, left side with VDS
534 mm
Lift height max of dozer blade above subgrade
380 mm
Lift height max of dozer blade above subgrade with VDS
388 mm
Scraping depth max of the dozer blade below subgrade
419 mm
Scraping depth max of the dozer blade below subgrade with VDS
411 mm
Distance of bucket dozer blade (short DS)
354 mm
Distance of bucket dozer blade (short DS) with VDS
326 mm
Distance of bucket dozer blade (long DS)
259 mm
Distance of bucket dozer blade (long DS) with VDS
218 mm
Boom slewing radius center
2,080 mm
Boom slewing radius center with VDS
2,054 mm
Boom slewing radius right
1,960 mm
Boom slewing radius right with VDS
1,943 mm
Boom slewing radius left
1,641 mm
Boom slewing radius left with VDS
1,640 mm
Length total traveling gear
2,006 mm
Length total traveling gear with VDS
2,021 mm
Width dozer blade
1,570 mm
Height dozer blade
300 mm
Length
2,006 mm
Turning angle max of the arm system to the right
50 °
Turning angle max of the arm system to the left
75 °
Non-VDS (long dipper) length x width x height
169"(4290 mm) x 61.8"(1570 mm) x 94.8"(2414 mm)
VDS length x width x height
165.3"(4199 mm) x 61.8"(1570 mm) x 99.5"(2526 mm)
Rubber track width
11.8"(300 mm)
Dozer blade
61.8"(1570 mm)
