Description
The EZ17 compact excavator is the best performing zero tail model in its class. The EZ17 is powered by a Tier 4 Final engine that offers excellent power, fuel economy and quiet operation. The EZ17 is the smallest zero tail excavator from Wacker Neuson combining a compact design, expandable undercarriage and 2- speed drive. The EZ17 provides maximum maneuverability and accessibility while still delivering an excellent digging depth and powerful bucket breakout force. The expandable undercarriage is adjustable to travel through narrow passages and low ground pressure protects existing landscaping.
Specifications
Manufacturer
Wacker Neuson
Model
EZ17
Year
2026
Category
Excavators
Subcategory
Tracked Zero Tail Excavators
Arm displacement to centre of bucket, left side
16.5 in
Arm displacement to centre of bucket, right side
21 in
Biting force max
2,046 lbf
Boom slewing radius - Left
54 in
Boom slewing radius - Middle
64.1 in
Boom slewing radius - Right
59.8 in
Breakout force max
4,204 lbf
Cabin - specified sound pressure level LpA acc to ISO 6394
79 dB(A) LpA
Chain width
9.1 in
Digging depth max
97.9 in
Digging depth max - Long Dipperstick
97.9 in
Digging depth max - Standard Dipperstick
91.6 in
Digging radius max
153.5 in
Digging radius max - Long Dipperstick
4,050 mm
Digging radius max - Standard Dipperstick
153.5 in
Dump height max
100.47 in
Dump height max - Long Dipperstick
100.4 in
Dump height max - Standard Dipperstick
95.9 in
Dumping height
95.9 - 100.4 in
Height
2,362 mm
Height - Dozer blade
9.1 in
Insertion depth - Long Dipperstick
73.4 in
Insertion depth - Standard Dipperstick
67.4 in
Insertion height - Long Dipperstick
140.8 in
Insertion height - Standard Dipperstick
136.3 in
Lift height -Above ground
10.7 in
Operating pressure Slewing gear
2,176 psi
Range - Long Dipperstick
157.6 in
Range - Standard Dipperstick
151.5 in
Rear swivel radius
26 in
Scraping depth - Below ground
15.4 in
Sound level (LwA) acc to 2000/14/EC
93 dB(A)
Transport length - Long Dipperstick
139.8 in
Transport length - Standard Dipperstick
141.1 in
Travel speed max
3 mph
Turning angle - Boom system to the left
65 °
Turning angle - Boom system to the right
57 °
Width
1,300 mm
Width - Undercarriage extended
51.2 in
Ground clearance
6.3 in
Height
93 in
Height - Dozer blade
230 mm
L x W x H
141.1 x 39 x 93 in
Length - Track
1,607 mm
Operating weight
3,801 - 4,299 lb
Shipping weight min
1,595 kg
Transport length - Long Dipperstick
3,551 mm
Transport length - Standard Dipperstick
3,584 mm
Width
51.2 in
Width - Canopy
34.8 in
Width - Undercarriage extended
1,300 mm
Width - Undercarriage retracted
39 in
